| Description Includes (1) Single Screw Extruder PME60/35, screw diameter: 60mm, screw length: 35D with degassing vacuum pump, barrel heating zones: 7x 20kW, throughput: 60-180kg/h, power: 70kW, with integrated electrical control cabinet with temperature controllers and all connections, continuously operating screen changer type L-026 with two channels, granulating nozzle for 20 strands, stainless steel water bath with deflection rollers and cooling fan, dosing unit with hopper, (2) Double Screen 800/300 stainless steel with double screen chute, round perforation 8mm for downstream connection of a transport suction unit, monitor control, strand pelletiser GR 250, infinitely variable collection heating, single knife, inclined cut, pneumatically pressed feed roller, outlet with slide (3) Dry Air Dryer E200 with one fully insulated 1000l V2A vessel, drying throughput: 250kg/h, stationary unit, easy cleaning when changing material due to pull and plug system, process controlled, with automatic boiler filling by material conveying system Z-AS/GV SFR 80, connected load: 18kW. |
|
| Make | Plastmachines |
|---|---|
| Model | PM 60/35 |
| Year of manufacture | 1993 |
| Price | On application |
| Offer No | INNO24853 |
